Gravity separator gold spiral concentrator for sale

FOB Reference Price:Get Latest Price
$400.00 - $800.00 / Set | 1 Set/Sets (Min. Order)
Model Number:
5LL-400
Power(W):
/
Lead Time:
Quantity(Sets) 1 - 5 >5
Est. Time(days) 10 Negotiable
Report Suspicious Activity
Overview
Quick Details
Warranty:
1 year
Place of Origin:
Jiangxi, China
Brand Name:
Hengcheng
Voltage:
/
Weight:
0.05 t
Certification:
ISO9001:2015
Type:
Gravity Separator, gravity separator
Condition:
New
Production Capacity:
0.15-0.2 t/h
Dimension(L*W*H):
460*460*1500
Applicable Industries:
Energy & Mining
Application:
copper process
Feeding size:
0.2-0.02 mm
Feeding density:
25-55%
Installation:
Engineer Guide
Product name:
Spiral chute separator
Keywords:
gold process equipment
Keywords 2:
spiral separator
Keywords 3:
spiral concentrator
Color:
Customers' Request
After-sales Service Provided:
Video technical support, Online support, Field installation, commissioning and training, Field maintenance and repair service
Supply Ability
Supply Ability:
100 Set/Sets per Month Urgent order could arrange overtime production
Packaging & Delivery
Packaging Details
Standard export package
Port
Xiamen port
Lead Time :
Quantity(Sets) 1 - 5 >5
Est. Time(days) 10 To be negotiated
Video Description

Gravity separator gold spiral concentrator for sale

Product Description



GENERAL DESCRIPTION:

   Spiral separator is our company's concentrating products which is the best concentrating equipment ,especially for the concentrating sand ore in beach ,riverside ,seashore and stream ,the product is made of the fiberglass line with wear-resistant resin and emery .it is the domestic advanced level, the new hightly effective equipment ,it has been widely used in to enrichment the particle size (0.3-0.22mm ) fine grain like iron,tin,chromite,ilmenite, tungsten ,zinc , tantalu,-niobium, gold ,coal,monazite,rutile,zircon,other low-grade ores or non metallic minerals which have enough specific gravity difference.

Gravity separator gold spiral concentrator for sale

     Our company uses the newest design and a complete set of technology organization produced and strict quality testing to guarantee each specification of spiral separator qualified .we make the serialized with a special kind of grooved spiral separator to be selected by colored ,ferrous metal mine ,coal chemical industry ,coal dressing ,sulfur factory as well as the scientific research ,the design department ,the colleges and universities test chamber.
    Our Spirals are made of polyurethane lined fiber glass with wearable corundum inner surface.
Generally there are 5 turns in one start, single, twin, triple and quad starts available per column to suit capacity requirements.

Gravity separator gold spiral concentrator for sale



Advantages & Charateristics
1. Reasonable structure and small occupation area


2. High recovery, high efficiency, and precise separation,


3. Light in weight, rust and corrosion resistant;


4. Simple installation and Minimal maintenance requirements


5. Low operating cost and long operating life


6. Reliable running with minimal operator attention


7. Strong adaptability to fluctuation of feeding amount, density, size and grade;



8. The surface of emery forms strong friction the concentration effect surpass plastic surface



9. Non -requirement power ,just used for water to get power



 Gravity separator gold spiral concentrator for sale



MACHINE STRUCTURE:



                               Working principle

1. Set up spiral separator  calibrate the vertical line, and fix it in proper position with iron or wood

2. By the pulp let mine to screw on the top two inlet, add sufficient moisture, adjust the concentration of pulp, pulp natural vortex, down from a height in the rotating velocity cant produce a kind of inertial centrifugal force, with the proportion of ore, granularity, shape differences, through the effect of gravity and centrifugal force cyclone, separate ore and sand, concentrate into a pipe with pipe joint, tailings backfilling materials flow in pipeline into the sandpool, with a sand pump discharge



TECHNICAL DATA:

 Model

5LL-4005LL-6005LL-9005LL-12005LL-1500
 Outside Dia (mm)40060090012001500
 Pitch(mm)   240.180 450.360.270  675.540.405   900.720.540      540.720
 Lateral slope9°9°9°9°
 Max start per unit 234-24-24-2
 Feeding size (mm)0.2-0.020.2-0.020.3-0.030.3-0.030.3-0.02
 Feeding density (%)25-5525-5525-5525-5525-55
 Capacity (t/h)0.15-0.20.8-1.22-34-68-6
 Dimensions(mm)460*460*1500700*700*16001060*1060*40001360*1360*52301560*1560*5230
 Weight (t)0.050.150.400.600.80



"Send" inquiry to know discount price and more techology



APPLICATION IN MINE SITES:

Rutile, ilmenite and zircon concentration
Iron ore, chromite and manganese beneficiation
Tin, tantalum and ore concentration
Gold, native copper and base metal recovery
Silica sands processing
Titano-magnetite concentration

Detailed list of  mineral grade :

Extracting gold in one-off ,recovery rate attainability under 98%



mineral

Grade

Tin

Above 50%

Tungsten

Above 50%

Titanium

Between 37%-40%

Iron

Between 58%-67%

Copper

Above 20%

sulphur

Above 30%

lead

Above 53%







 Customers visit Hengcheng Factory:

Related Products

 Gravity separator gold spiral concentrator for sale



Know more mining equipment please clike here our website :JIangxi Hengcheng Mining equipment Co.LTD  "Send" the inquiry to get low price discount

Company Information

Jiangxi Hengcheng Mining Equipment Company is specialized in manufacturing various kinds of mining equipment. We have served the mineral processing industry as an excellent mineral processing equipment manufacturer for over 20 years.
Hengcheng company is dedicated to provide a complete line of equipment including shaking table, spiral chute, jig machine,trommel,rotary scrubber, flotation machine, magnetic separator,grinding mill, and so on. We are involved in the range of mineral beneficiation services including mineral testing, process flowchart design, installation and commissioning, technical consulting, as well as staff training,etc. Our proven technologies and experience permit us to provide every customer with the most efficient & commercial benificiation  plant equipment. flow design and production equipment in line with your special needs.



 Gravity separator gold spiral concentrator for sale

certificates

Exhibition

Gravity separator gold spiral concentrator for sale

FAQ

1. Q: Can I visit your factory?
A: Yes. Many domestic and overseas customers visited our factory every year.

2. Q: What about the warranty of your equipment? Do you supply spare parts?
A: Our warranty is one year(12 months), and we can supply spare parts also.

3. Q: Do you provide after-sales service?
A: Yes. We have a professional after-sale service team to promptly and thoroughly solve your problems.

4. Q: Do you provide equipment operation training?
A: Yes. We can send professional engineers to the working site for equipment installation, adjustment, and operation training. All of our engineers have passport.

5. Q: Do you provide producution flow chart?
A: Yes. Our experienced engineers are specialized in designing process flow for various ores beneficiation, including iron ore, tin ore, copper ore, gold ore, lead zinc ore, manganese ore, etc.

6. Q: Can you test our sample ore?
A: Yes. You can send your samples to us for testing and analysis.

7. Q: Have you made the whole ore dressing lines?
A: Yes. We have made many large&small scale ore dressing lines at home and abroad.



Contact Us

How To Contact Us?

Send your inquiry details in the below, Click “Send” Now!



contact Bella



inquiry

If you are interested in our products,welcome to contact us.

↓↓↓
